eGraf® HiTherm™
Thermal Interface MaterialseGraf® HiTherm™ thermal interface materials (TIMs) are designed for long-life, mission-critical applications that have extreme heat cycles, require low contact resistance, and high thermal conductivity. HiTherm TIMs are thermal interface sheets made of flexible graphite specifically engineered for demanding solid-state lighting, computing, and power electronics applications.
HiTherm TIMs are typically used in the following applications:
In a typical application, less than 5% of the surface area has actual metal-to-metal contact. The parts of the surfaces that are not in direct contact with each other will have small air gaps between them. This "interstitial air" is a very poor thermal conductor and can keep heat from flowing from the hotter plate to the colder one.
Many substances can be used as thermal gap pads, including thermal grease, polymer pads, soft metals, and graphite. The best solution to improve heat flow is to use HiTherm TIMs, a thin, soft, thermally conductive layer between the two surfaces. HiTherm TIMs will drive out the interstitial air and replace it with low thermal impedance graphite.
Additional benefits of HiTherm materials include the following:
When determining which grade and thickness of HiTherm TIM will work for your application, the effective thermal impedance is the critical factor. Thermal impedance combines the thermal resistance at the contact surfaces and the TIM's bulk resistance.
HiTherm TIMs are available in standard and compressible versions. Many grades can be laminated with adhesives for easy peel and stick application. All HiTherm flexible graphite materials can be die-cut to ensure an exact fit and reduce module-to-module variation during assembly. Non-compressible flexible graphite is ideal for when both surfaces are parallel with each other. Compressible flexible graphite improves surface contact, reduces thermal impedance, and compensates for flatness variation between contact surfaces, while the high in-plane thermal conductivity reduces hot spots.
Innovative Graphite Materials for Medical and Diagnostic Devices
SpreaderShield™ flexible graphite heat spreaders often play a critical role in thermal management in many kinds of medical d
NeoGraf’s global team of application engineers specialize in developing and manufacturing high-quality flexible natural and synthetic graphite material solutions for today’s advanced applications. Regardless of your product design phase (concept, prototyping, or mass production), we offer technical answers and thermal modeling support to some of your most challenging problems with a fast response time. Are you looking for a thinner, more powerful material that can achieve better heat spreading? Contact us, and we can help you get started.
HiTherm™ Thermal Interface Materials - Providing the Vital Thermal Link
Many substances have been used as thermal interface materials, including oily pastes, grease, soft metals, and now HiTherm™ flexible graphite.
eGraf® thermal management products, solutions and processes have earned the following proprietary rights:
A Thermal Management System: CA2401619; CN1874889; CN101091423; CN205564920; CN205692938; CN207369488; EP1536313; EP1680274; EP1742524; EP2026164; EP2296454; EP2973840; JP3204114; JP3206039; JP3213925; JP4555300; KR10-1168099; KR10-0935275; KR20-0486521; MX241283; US6758263; US6777086; US6982874; US7161809; US7292441; US7573717; US7799428; US7889502; US8955983; US9664368; US9673494; US10177070; TWI278275; TWI316842; TWM487605; TWM505066
Battery Thermal Management: CN203398243; CN203398244; CN203950846; CN203950871; CN203481336; CN204128420; KR20-0479471; KR10-2006430; KR20-0479460; KR20-04810140; KR20-0482438; KR20-0485795; KR20-0487029; JP3183200; JP3195255; US9343784; US9368843; US9444123; US9716296; US9774063: US9797664; US10587019; D701166; D709027
Display: CN1617661; CN17255945; CN1892320; CN102159060; CN102573415; EP1673754; EP1739708; EP2528424; KR737231; KR767558; KR10-0768630; KR10-0830526; KR10-0938749; KR10-1012168; KR10-1055051; MX270438; US7138029; US7150914; US7160619; US7276273; US7658999; US7666270; US8211260; US9081220: US9087669; US9104058; US9250462; US9253924; US9253932; US9653763; US9761403; US10440865; TWI277998; TWI294600; TWI304375; TWI369936
Flexible graphite sheet: CA2557497; CN203415567; EP1384261; EP 1467856; KR20-0478915; JP3186199; US6673284; US6746768; US6777086; US7166912; US9267745; US10744736
Flexible circuit: US9546763; US9546764; US10094516
Heat Sink: US6538892; US6749010; US6771502; D662898; D677227;
HiThermTM Flexible Graphite: EP1467856; JP3207324; KR20-0492216; US6746768; US10589998; TWM510925
Are you looking for a more reliable thermal interface material for your long-life application? Contact us, and we can help you get started.
